BIESSE AKRON 430 EDGEBANDER
Equipment Location: Rimouski, QC
| Lot Closes: |
|
(3/6/2017 2:05 PM EST)
|
|
Event:
|
|
Armoires Distinction
|
|
Brand/Model:
|
|
BIESSE "AKRON 430"
|
|
Year MFG:
|
|
2008
|
|
Machine Type:
|
|
EDGEBANDER
|
|
Serial #:
|
|
4349
|
|
Elect./Voltage:
|
|
600V, 60 Cy, 3 Ph.
|
|
Location:
|
|
Rimouski, QC
|
|
Condition:
|
|
Good condition
|
| *Dimensions: | | 192" L x 48" W x 60" H |
| *Weight: | | 4,000 Lbs (estimate) |
|
Loading:
|
|
Rigger Required
|
|
Comment:
|
|
Single Sided Edgebander!
|
|
Buyer Premium:
|
|
12.5%
|
Description:
(view full)
Single Sided Edgebander! Machine Capacity: Thickness of banding rolls 0.4 - 3 mm (0.12"), Thickness of strips (HPL, veneer, solid wood strips) .0.4 - 12 mm (0.47"). Panel thickness 60 mm (2.4") max. & 10 mm min., Minimum panel length 140 mm.(5.5"). Minimum panel width 85 mm (3.3") Feed/Glue Unit: automatic strip & coil feed magazine with robust shear-type 3 mm PVC guillotine Hot Melt glue system, 10 Minute heat-up time with Teflon coated gluepot, digital thermostats with automatic kick-down when machine is in idle mode. 1" Dia. glue applicator roller; pressure section with (1) large dia. "non-stick" coated drive roller & (2) chrome plated idle rollers with pneumatic positioning Workstations: Inclined travel Front & Rear End Trims: (0.33 HP - 12,000 RPM motors), motors travel on (2) straight slides and pneumatic tilt 0° - 25° on horz. plane Tilting Top & Bottom Trimming Unit with: (2) Motors 0.65 KW (0.87 HP) each - "Pro-nesting" copiers - Cutters R=2 mm. Top & Bottom Profile Scrapers with digitals for horz. adjustments Top & Bottom Glue Scrapers, digitals for horiz. adjustments Top & Bottom Buffing Units Feed Speed of 12 MPM (39 FPM), 3 HP feed drive. NOTE: All bidding is in US Dollars; payment must be in US-Currency
|
