GANNOMAT SYSTEM LINE 310 BORING (2-HEAD LINEBORER)
Equipment Location: MILWAUKEE, WI
| Lot Closes: |
|
(9/26/2023 3:05 PM EST)
|
|
Event:
|
|
Milwaukee Fabrications
|
|
Brand/Model:
|
|
GANNOMAT "SYSTEM LINE 310"
|
|
Year MFG:
|
|
1988
|
|
Machine Type:
|
|
BORING (2-HEAD LINEBORER)
|
|
Serial #:
|
|
165 842
|
|
Elect./Voltage:
|
|
220 V, 60 Cy, 3 Ph.
|
|
Location:
|
|
MILWAUKEE, WI
|
|
Condition:
|
|
Good condition
|
| *Dimensions: | | 0" L x 0" W x 0" H |
| *Weight: | | 0 Lbs (estimate) |
|
Loading:
|
|
Seller Loading
|
|
Comment:
|
|
|
|
Buyer Premium:
|
|
15%
|
Description:
(view full)
Specifications: (2) 23-spindle vertical boring heads on 32 mm centers, drills from the bottom-up, 2 HP - 2,850 RPM motor on ea. head.
- 2-Step drill cycle with through boring.
- 3" (75 mm) Drilling stroke.
- 48" x 58" Worktable size, 34" working height.
- Min. distance between rows is 7", max. distance is 25-3/8", 4" (100 mm) max. workpiece thickness.
Complete with: (6) Pneumatic hold-down clamps, (1) 59" & (2)78" long back fences with (8) flip-stops, 10 mm straight shank spindles, and pneumatic foot pedal actuator.
Machine State: Disconnected and Stored, Inspection: Available for Inspection (By Appointment Only)
|
Specifications: (2) 23-spindle vertical boring heads on 32 mm centers, drills from the bottom-up, 2 HP - 2,850 RPM motor on ea. head.
- 2-Step drill cycle with through boring.
- 3" (75 mm) Drilling stroke.
- 48" x 58" Worktable size, 34" working height.
- Min. distance between rows is 7", max. distance is 25-3/8", 4" (100 mm) max. workpiece thickness.
Complete with: (6) Pneumatic hold-down clamps, (1) 59" & (2)78" long back fences with (8) flip-stops, 10 mm straight shank spindles, and pneumatic foot pedal actuator.
Machine State: Disconnected and Stored, Inspection: Available for Inspection (By Appointment Only)
