BUTFERING E-LINE 313 RRL WIDE BELT (50" - 90", 3-HEAD)
Equipment Location: WEST PALM BEACH, FL
| Lot Closes: |
|
(11/19/2024 3:55 PM EST)
|
|
Event:
|
|
Blumer & Stanton and Oliveri Millworks
|
|
Brand/Model:
|
|
BUTFERING "E-LINE 313 RRL"
|
|
Year MFG:
|
|
2001
|
|
Machine Type:
|
|
WIDE BELT (50" - 90", 3-HEAD)
|
|
Serial #:
|
|
68779
|
|
Elect./Voltage:
|
|
440 V, 60 Cy, 3 Ph.
|
|
Location:
|
|
WEST PALM BEACH, FL
|
|
Condition:
|
|
Very good condition
|
| *Dimensions: | | 100" L x 80" W x 80" H |
| *Weight: | | 0 Lbs (estimate) |
|
Loading:
|
|
Rigger Required
|
|
Comment:
|
|
Complete with combination head!
|
|
Buyer Premium:
|
|
15%
|
Description:
(view full)
BÜTFERING E-LINE 313 RRL 1,350 mm (53.15") 3-Head Wide Belt Sander, with Combination Head
Specifications:
- Max. thickness cap. 5-7/8”.
- Variable feed speeds 2.5 - 13 MPM (8-1/2 - 42 FPM).
Equipped with: - 1st Head: 8” Dia. Grooved rubber-covered contact roll, with 22 kW (29-1/2 HP) - 2,930 RPM Motor.
- 2nd Head: 8” Dia. Grooved rubber-covered contact roll, with 18.5 kW (25 HP) - 3,535 RPM Motor.
- 3rd Head: Combination head, with 5-1/2” Dia. Grooved rubber-covered contact roll, 3-1/2" Dia. Smooth steel contact roll, 2-1/4" W Finishing platen, & 18.5 kW (25 HP) - 3,535 RPM Motor.
- All heads with Pneumatic belt tensioning and Infeed & Outfeed Pinch rolls.
- 53” W x 6-1/2’ L Feed belt, with 1.5 kW (2 HP) - 1,725 RPM Motor & 11” L Infeed extension with (2) 1-7/8” Dia. Rollers on 6” Centers.
- Control, with Control stick & LED Display for programmable thickness adjustment, and Motor load meters.
|
BÜTFERING E-LINE 313 RRL 1,350 mm (53.15") 3-Head Wide Belt Sander, with Combination Head
Specifications:
- Max. thickness cap. 5-7/8”.
- Variable feed speeds 2.5 - 13 MPM (8-1/2 - 42 FPM).
Equipped with: - 1st Head: 8” Dia. Grooved rubber-covered contact roll, with 22 kW (29-1/2 HP) - 2,930 RPM Motor.
- 2nd Head: 8” Dia. Grooved rubber-covered contact roll, with 18.5 kW (25 HP) - 3,535 RPM Motor.
- 3rd Head: Combination head, with 5-1/2” Dia. Grooved rubber-covered contact roll, 3-1/2" Dia. Smooth steel contact roll, 2-1/4" W Finishing platen, & 18.5 kW (25 HP) - 3,535 RPM Motor.
- All heads with Pneumatic belt tensioning and Infeed & Outfeed Pinch rolls.
- 53” W x 6-1/2’ L Feed belt, with 1.5 kW (2 HP) - 1,725 RPM Motor & 11” L Infeed extension with (2) 1-7/8” Dia. Rollers on 6” Centers.
- Control, with Control stick & LED Display for programmable thickness adjustment, and Motor load meters.
